The NOVA RFID reader is an ideal solution for flush mount readers. NOVA readers fit perfectly into a standard 55 mm switchbox and can be completed with any cover plate to match the site’s interior and architecture.

When in need of a reader for flush mounting, ProxTech’s NOVA is the perfect answer.

NOVA fits perfectly on a 55 mm switchbox to allow fast and easy connection. The RFID reader is supplied as ‘PCB only’ so you can complete it with a cover plate of your choice. We recommend GIRA system 55 but of course, you can pick any cover plate of your choice.

The NOVA RFID reader is available with a choice of Wiegand, Clock&Data, TTL, RS232, RS485 or customer specific interfaces.
A 3-colour LED and buzzer enhance user feedback.

NOVA Versionen :
  • NOVA-EM: 125 KHz reader for EM4x02 transponders
  • NOVA-HT: 125 KHz reader for Hitag transponders
  • NOVA-MF: 13,56 MHz reader for MIFARE transponders
  • NOVA-LG: 13,56 MHz reader for Legic transponders
  • NOVA-FLEX: 13,56 MHz reader for multi-ISO transponders (ISO14443, ISO15693, ISO18092 NFC)

Technical specifications

  • Dimensions: 69 x 69 mm
  • Supported transponder types
    • on 125 kHz : EM4x02 family and equivalent, or Hitag
    • on 13,56 MHz : MIFARE or Legic
  •  Antenna integrated on base plate
  • Interface: Wiegand, Clock/Data, TTL or customer specific ( RS485 or RS232 on request )
  •  Read range ( values depending on transponder types, power supply and ambient environment )
    • on 125 kHz : up to 100 mm
    • on 13,56 MHz : up to 80 mm
  • Stromversorgung : 9 bis 24 Vdc ( 5 % )
  • Temperaturbereich : -20°C bis +60°C
  • Mit integriertem Summer und dreifarbiger LED zur Statusanzeige
  • Einbau in handelsübliche 55er Unterputzdose

Download following datasheets

Datasheet NOVA
