RFID USB reader for wall mount
Besides the well-known USB desktop readers and USB stick PEN readers, ProxTech can also supply you with a wall-mount RFID reader with USB interface.This can be extremely useful when for example in need of adding a RFID reader to a processor unit or a time clock.
When thinking of RFID readers with USB interface, this is often limited to desktop readers or pen readers. However, it might come in handy when you would have a wall mount reader which can be connected over USB.
Or simply when you need a waterproof or shockproof USB RFID reader to use in an industrial environment.
This is exactly where ProxTech’s 13.56 MHz MCR and MINI RFID reader series come in. Not only available with the standard interfaces Wiegand, Clock/Data, RS232, RS485, …, they can also be supplied with a USB 2.0 interface in HID mode (keyboard emulation).
Wall-mount RFID USB reader versions:
- MCR-MF: 13,56 MHz reader for MIFARE transponders
- MCR-LG: 13,56 MHz reader for Legic transponders
- MCR-ISO: 13.56 MHz reader for multi-ISO transponders (ISO14443, ISO15693, ISO18092 NFC)
- MCR-FLEX: 13,56 MHz reader for multi-ISO transponders (ISO14443, ISO15693, ISO18092 NFC, LEGIC Prime, LEGIC advant)
- MINI-MF: 13,56 MHz reader for MIFARE transponders
- MINI-LG: 13,56 MHz reader for Legic transponders
- MINI-ISO: 13,56 MHz reader for multi-ISO transponders (ISO14443, ISO15693, ISO18092 NFC)
- MINI-FLEX: 13,56 MHz reader for multi-ISO transponders (ISO14443, ISO15693, ISO18092 NFC, LEGIC Prime, LEGIC advant)
Technical specifications MCR
- Dimensions: 80 x 80 x 18 mm (An optional mounting support ( 20mm ) is added to each reader.)
- Interface: to be specified when ordering
- USB 2.0 HID mode (keyboard emulation)
- Wiegand (several bitblock lengths available)
- Clock & Data (several number of characters available)
- RS232 (9600, 4800 or 2400 Bd)
- TTL (9600, 4800 or 2400 Bd)
- RS485
- customer specific interfaces available on request
- Read range with internal antenna (values depending on transponder types, power supply and ambient environment) on 13,56 MHz up to 80 mm
- Power supply : 5 Vdc or 9 … 24 Vdc
- Duplicate read control
- Indications : 3 LED’s ( red / yellow / green ) + buzzer
- Wiring : screw connector block (12 pins)
- Protection rate : IP65 ( depending on mounting method )
- Operating temperature : -20 °C to + 60 °C
- Integrated antenna and electronics
- Fully potted housing allows easy installation both in- as outdoor
- Available in black or white housing
Technical specifications MINI
- Dimensions: 135 x 49 x 20 mm
- Interface: to be specified when ordering
- USB 2.0 HID mode (keyboard emulation)
- Wiegand (several bitblock lengths available)
- Clock & Data (several number of characters available)
- RS232 (9600, 4800 or 2400 Bd)
- TTL (9600, 4800 or 2400 Bd)
- RS485
- customer specific interfaces available on request
- Read range with internal antenna ( values depending on transponder types, power supply and ambient environment ) on 13,56 MHz up to 80 mm
- Power supply : 5 Vdc or 12 Vdc
- Duplicate read control
- Indications : 2 LED’s ( red /green ) + buzzer
- Wiring : 8-wire cable ( approx. 1 m long, other lengths on request )
- Protection rate : IP65 ( depending on mounting method )
- Operating temperature : -20 °C to + 60 °C
- Integrated antenna and electronics
- Fully potted housing allows easy installation both in- as outdoor
Download following datasheets
